Newton Industrial
Large-Scale Automation Made Easy
The ESL Made for Industry 4.0
Low-Interference Connection
High-Speed Data Transmission
1-second LED blinking speed
Faster display update time
Transforming supply chain operations in ways that static signage cannot.
IoT deployment on a commercial scale can be difficult and intimidating. However, the Newton Industrial ESL can help make the transition easier. SOLUM’s newest ESL is designed specifically for use in a busy industrial environment where heavy machinery and metal equipment are common.
As a response, SOLUM took our best-selling Newton technology and fitted it with these features to make it ideal for industrial businesses. In an environment where processes are scrupulously done and there is no room for error, the Newton Industrial is a beneficial upgrade for any warehouse, distribution center, or factory.
{1) Left Image section
Industrial-Grade Connectivity
Newton Industrial is one of the fastest ESL options made for large-scale commercial use. It features a 1-second reaction time for LED blinking, which helps optimize pick-by-light assembly. Additionally, the fully graphic black and white e-paper technology of Newton Industrial enables ultra-fast update and display time.
(2) Desktop Version - Right image
Interactive lights
Newton Industrial is equipped with a blinking LED feature that can display 7 different colors - opening a wide variety of use cases for your industrial processes.
(2) Mobile Version - Right image
Interactive lights
Newton Industrial is equipped with a blinking LED feature that can display 7 different colors - opening a wide variety of use cases for your industrial processes.
(4) Desktop Version - Right image
Special 4.3” LED picking model
Newton Industrial also comes in a 4.3” LED Picking model, a special variant designed for digitized order picking process. It’s LED-lit programmable button allows your order pickers to complete an order picking and replenishment process with extreme precision and efficiency.
(4) Desktop Version - Right image
Location-based service
Track workers’ movements, shelf activity, and moving equipment across your construction site or facility, no matter where they are.
(4) Mobile Version - Right image
Location-based service
Track workers’ movements, shelf activity, and moving equipment across your construction site or facility, no matter where they are.
- Desktop View
Built for industrial environment
The Newton Industrial is reinforced with added protection to withstand different industrial site conditions.
Streamline your operations with Newton Industrial.
Fast, Dependable and Robust
Stay on top of workflows and worker safety
Section 10
Technical Specifications
| Dimensions (WxHxD) |
76.0 × 49.5 × 10.45 (mm) 2.99 × 1.95 × 0.41 (in)
|
| Display |
Active Display Area 57.3 × 38.2 (mm) Resolution 300 x 200 pixels Pixel density 133 dpi Display technology Full Graphic E-ink Display Pixel colors BWRY (Black, White, Red, Yellow) Viewing angle Nearly 180˚ |
| Page capacity |
Up to 7 pages |
| Operating temperature |
0 - 40°C 32 - 104°F |
| Battery |
Type and number CR2450 × 2 Battery lifetime Up To 10 years (2 Update/day) |
| Encryption |
128-Bit AES |
| Compliance |
FCC, IC, CE, TELEC, KC, RoHS |
| NFC |
FeliCa NFC Forum Type 3 |
| Protection from water and dust |
IP68 |
| External components |
Button 1 Buttons LED 7 Colors (Red / Green / Blue / Yellow / Cyan / Magenta / White) |
| ESL operating frequency |
2.4 Ghz |
| Wireless firmware update |
Yes |
